Hyundai Palisade oil capacity depends on the model year and engine. Most 2020 through 2025 models use a 3.8L V6 engine with similar oil requirements. However, Hyundai changed the engine lineup for the 2026 Palisade. This change also affected the required oil capacity and viscosity.
Using the correct oil amount protects the engine during normal operation. Too much oil can increase crankcase pressure and interfere with lubrication. Too little oil can reduce protection for bearings, pistons, and other moving parts. For this reason, drivers should confirm the final oil level after every oil change.
This guide covers Hyundai Palisade oil capacity from 2020 through 2026. It compares capacity by model year and engine in both quarts and liters. You will also find the recommended oil type and viscosity for each relevant engine. Later sections explain oil filter considerations and the correct way to check the oil level. Use the table below to find the specification for your Hyundai Palisade.
How Much Oil Does a Hyundai Palisade Take?
A Hyundai Palisade takes between 5.8 and 6.5 liters of engine oil, depending on the model year and engine. Most 2020 through 2025 models use 6.5 liters. However, the redesigned 2026 Palisade uses 5.8 liters for both gasoline and hybrid powertrains.
Hyundai lists 6.86 US quarts, or 6.5 liters, for the 2025 Palisade. This specification applies to its 3.8L V6 engine. In addition, Hyundai recommends SAE 5W 30 oil for this model year.
The 2026 Palisade uses a lower drain and refill capacity. Specifically, Hyundai lists 6.13 US quarts, or 5.8 liters, for the gasoline model. At the same time, Hyundai recommends SAE 0W 20 oil for this engine.
The 2026 Palisade Hybrid also takes 6.13 US quarts, or 5.8 liters. However, Hyundai recommends SAE 0W 30 for the hybrid powertrain. Therefore, both 2026 versions share the same oil capacity but use different viscosity grades.
| Model Year | Engine | Oil Capacity | Recommended Viscosity |
|---|---|---|---|
| 2020 | 3.8L V6 | 6.5 L | Check owner manual |
| 2021 | 3.8L V6 | 6.5 L | Check owner manual |
| 2022 | 3.8L V6 | 6.5 L | Check owner manual |
| 2023 | 3.8L V6 | 6.5 L | Check owner manual |
| 2024 | 3.8L V6 | 6.5 L | Check owner manual |
| 2025 | 3.8L V6 | 6.86 US qt / 6.5 L | SAE 5W 30 |
| 2026 | 3.5L V6 | 6.13 US qt / 5.8 L | SAE 0W 20 |
| 2026 Hybrid | 2.5L Turbo Hybrid | 6.13 US qt / 5.8 L | SAE 0W 30 |
The table shows why model year matters when checking Hyundai Palisade oil capacity. For example, a 2025 owner should not use the 2026 quantity as a refill target. The difference between these specifications is about 0.7 liter.
Oil capacity also refers to a specific service condition. In this case, Hyundai describes the 2026 figure as a drain and refill amount. However, some oil can remain inside engine passages after draining. Therefore, the listed number may not equal the exact amount needed during every oil change.
For that reason, drivers should not pour in the full listed capacity at once. Instead, add most of the required oil first. Then run the engine so the oil can circulate through the system. Afterward, allow the oil to settle and check the dipstick. Finally, add more oil only when the level remains below the correct range.
Why Did Hyundai Palisade Oil Capacity Change for 2026?
Hyundai Palisade oil capacity changed for 2026 because Hyundai introduced a new generation with different powertrains. The previous generation used a 3.8L V6 engine. In contrast, the 2026 lineup introduced new gasoline and hybrid configurations.
Engine design directly affects oil capacity. For example, the oil pan, lubrication passages, oil pump, filter system, and internal clearances influence total oil volume. Therefore, engine displacement alone cannot determine the correct capacity.
The 2025 Palisade provides a useful comparison. Its 3.8L V6 requires 6.5 liters of engine oil. In addition, Hyundai pairs this capacity with SAE 5W 30 oil.
The 2026 gasoline Palisade reduces the capacity to 5.8 liters. At the same time, Hyundai changes the viscosity recommendation to SAE 0W 20. Moreover, the oil must meet the required API or ILSAC specification.
The hybrid model also uses a 5.8 liter capacity. However, Hyundai recommends SAE 0W 30 for this powertrain. As a result, capacity alone cannot identify the correct engine oil.
This generation change creates a common risk for owners searching online. For instance, a specification for a 2025 Palisade does not automatically apply to a 2026 model. Therefore, owners should always match the specification to the correct model year.
The process is straightforward. First, confirm the model year. Next, identify the engine. Then check the required oil capacity and viscosity. Finally, verify the oil level with the dipstick after the refill. This sequence reduces the risk of using specifications from another Palisade generation.
What Type of Oil Does a Hyundai Palisade Need?
A Hyundai Palisade needs engine oil that matches its model year, engine type, and manufacturer specification. Oil capacity tells drivers how much oil the engine requires. However, oil type and viscosity determine how the oil performs inside the engine.
For 2020 through 2025 Hyundai Palisade models, the 3.8L V6 engine uses SAE 5W 30 engine oil. Hyundai recommends oil that meets the required performance standards listed in the owner’s manual. Therefore, owners should check both the viscosity grade and the approved specification before buying oil.
The 2026 Hyundai Palisade uses different oil requirements because Hyundai introduced new powertrains. The 3.5L V6 gasoline model uses SAE 0W 20 oil. In contrast, the 2026 Palisade Hybrid uses SAE 0W 30 oil.
These viscosity differences exist because engine design affects lubrication needs. For example, newer engines may use different internal clearances, temperature management systems, and efficiency targets. As a result, Hyundai selects different oil grades for different engines.
Drivers should also understand the difference between oil capacity and oil viscosity. Capacity answers the question, “How much oil does the engine need?” Viscosity answers the question, “How does the oil flow at different temperatures?” Both specifications matter during an oil change.
Using the correct oil grade helps the engine maintain proper lubrication during startup, normal driving, and high temperature operation. In addition, it helps the engine achieve the performance and efficiency targets designed by Hyundai.
Before purchasing engine oil, owners should confirm three details. First, check the Palisade model year. Second, identify the engine type. Finally, match the oil viscosity and specification listed by Hyundai.
This approach prevents a common mistake among vehicle owners. Many drivers choose oil based only on the vehicle name. However, the same Hyundai Palisade name can include different engines with different lubrication requirements.
Does Hyundai Palisade Oil Capacity Include the Oil Filter?
Hyundai Palisade oil capacity refers to the amount required for a specific oil service procedure, including normal drain and refill conditions. However, the exact amount needed during an oil change can vary slightly because some oil remains inside the engine and lubrication system.
During an oil change, technicians remove old oil from the oil pan and replace the oil filter. The new filter absorbs a small amount of fresh oil before the engine reaches normal operation. Therefore, the final refill amount may differ slightly from the capacity listed in the owner’s manual.
For example, a Hyundai Palisade with a listed capacity of 6.5 liters does not always require exactly 6.5 liters from the first pour. Some oil remains in internal passages after draining. In addition, the new oil filter needs time to fill after startup.
The correct procedure involves adding oil gradually. First, add the recommended amount in stages. Next, start the engine briefly to circulate the oil. Then, turn off the engine and wait for the oil level to stabilize.
Finally, check the dipstick and adjust the level if necessary. The dipstick provides the final confirmation because it shows the actual oil level inside the engine after the refill process.
This method reduces the risk of overfilling. It also prevents underfilling when a small amount of oil remains outside the engine after drainage.
For Hyundai Palisade owners, the listed oil capacity works as a maintenance reference. However, the final oil level should always come from the physical oil level check after service.
How Much Oil Should You Add After Draining a Hyundai Palisade?
You should add the recommended Hyundai Palisade oil capacity gradually after draining the old oil. The listed capacity provides a service target, but the final amount depends on the actual oil remaining inside the engine after drainage.
During an oil change, some old oil can remain in internal engine areas. For example, small amounts of oil may stay inside lubrication passages, the oil filter housing, and other engine components. Therefore, the amount needed after draining may differ slightly from the full factory capacity.
A proper refill process starts with adding most of the recommended oil amount. Next, start the engine for a short period so the new oil can move through the lubrication system. After that, turn off the engine and allow the oil to return to the oil pan.
Finally, check the oil level with the dipstick. If the level remains below the recommended range, add small amounts of oil until it reaches the correct position. This method provides a more accurate result than adding the entire capacity immediately.
The same process applies to different Hyundai Palisade generations. However, the target amount changes according to the engine. A 2025 Palisade with the 3.8L V6 requires about 6.5 liters, while a 2026 Palisade requires about 5.8 liters.
For this reason, owners should always confirm the model year and engine before performing an oil change. Using the wrong capacity can create unnecessary maintenance problems.
How Do You Check the Oil Level After Changing the Oil?
You check the Hyundai Palisade oil level by using the dipstick after the engine reaches operating temperature and the oil settles. This step confirms whether the refill amount matches the engine’s actual requirement.
First, park the vehicle on a flat surface. A level surface allows the oil to collect evenly inside the oil pan. Next, run the engine until it reaches normal operating temperature, then turn the engine off.
After shutting down the engine, wait several minutes before checking the oil level. This waiting period allows oil inside the engine passages to flow back into the oil pan. As a result, the dipstick provides a more accurate measurement.
Remove the dipstick and clean it before taking the final reading. Then insert it again and check the oil mark. The oil level should remain between the minimum and maximum indicators.
If the level appears too low, add oil slowly and check again. However, avoid adding large amounts at once because excessive oil can create new problems.
Hyundai’s owner manuals provide specific oil checking procedures for each generation. For example, the 2025 Palisade manual instructs owners to wait before confirming the final oil level after adding engine oil. Therefore, following the correct procedure helps maintain proper lubrication.
Checking the dipstick is the final step because the listed oil capacity is only a reference value. The actual engine oil level determines whether the vehicle has the correct amount of lubricant.
What Happens If You Put Too Much Oil in a Hyundai Palisade?
Putting too much oil in a Hyundai Palisade can interfere with normal engine lubrication and operation. Excess oil does not improve engine protection. Instead, it can create conditions that reduce lubrication efficiency.
When the oil level becomes too high, the crankshaft can contact the oil and create air bubbles. This process reduces the oil’s ability to form a stable protective layer between moving engine parts.
In addition, excessive oil can increase pressure inside the crankcase. As a result, oil may move into areas where it does not belong, including the intake system or seals.
Overfilling can also make it harder for the engine to manage heat. Proper oil circulation depends on the correct oil volume. Therefore, maintaining the recommended level helps the lubrication system work as designed.
If a Hyundai Palisade shows an oil level above the maximum mark, owners should correct the problem before extended driving. Removing the excess oil restores the correct operating condition.
The best prevention method is simple. Add oil according to the correct model year specification, then confirm the level with the dipstick. This approach avoids overfilling while ensuring the engine receives enough lubrication.
What Happens If a Hyundai Palisade Does Not Have Enough Oil?
A Hyundai Palisade with insufficient oil may experience reduced lubrication and increased engine wear. Engine oil protects internal components by reducing friction and carrying heat away from moving parts.
When oil levels drop too low, the oil pump may struggle to maintain consistent oil pressure. Consequently, some engine components may receive less lubrication than required.
Low oil levels can increase friction between parts such as bearings, pistons, and cylinder walls. Over time, this condition can accelerate wear and reduce engine reliability.
Insufficient oil can also affect engine temperature control. Since oil helps transfer heat away from internal components, a lower oil volume reduces the system’s ability to manage heat.
Warning signs may include an oil pressure warning light, unusual engine noise, or visible oil leaks. However, drivers should not wait for symptoms before checking the oil level.
Regular oil level checks provide a simple way to prevent damage. Therefore, Hyundai Palisade owners should verify the oil level after every oil change and follow the recommended maintenance schedule.
Does FWD or AWD Change Hyundai Palisade Engine Oil Capacity?
FWD and AWD configurations do not change Hyundai Palisade engine oil capacity when they use the same engine specification. The amount of engine oil depends mainly on the engine design, not the drivetrain layout.
For example, a Hyundai Palisade with the 3.8L V6 engine uses the same engine oil capacity whether it has front wheel drive or all wheel drive. The engine requires the same amount of lubricant because the internal lubrication system remains the same.
However, AWD models include additional drivetrain components. These components use separate fluids that do not affect engine oil capacity. For example, the transfer case and rear differential require their own maintenance fluids.
Therefore, owners should avoid confusing engine oil capacity with other vehicle fluid capacities. Engine oil protects internal engine components, while drivetrain fluids protect systems that transfer power to the wheels.
This distinction becomes important during maintenance. A vehicle may require several different fluids, but each fluid has a separate specification and service procedure.
When checking Hyundai Palisade oil capacity, owners should focus on three factors. First, identify the model year. Second, confirm the engine type. Finally, check the official oil capacity specification for that engine.
How Often Should You Change the Oil in a Hyundai Palisade?
Hyundai Palisade oil changes should follow the maintenance schedule for the specific model year and driving conditions. Oil capacity tells owners how much oil the engine needs, but it does not determine when the oil requires replacement.
Normal driving conditions usually allow longer oil change intervals compared with severe driving conditions. However, frequent short trips, heavy traffic, extreme temperatures, towing, and dusty environments can increase oil stress.
For example, an owner who drives mainly short distances may need more frequent oil changes than someone who drives longer highway routes. This happens because the engine may spend more time below its ideal operating temperature.
In addition, regular oil changes help maintain the benefits of the correct oil capacity. Fresh oil supports lubrication, heat control, and engine cleanliness. Therefore, using the correct oil quantity is only one part of proper engine maintenance.
Hyundai Palisade owners should combine three maintenance steps. First, use the correct oil capacity. Second, choose the correct oil viscosity. Finally, follow the recommended service schedule.
A complete maintenance approach protects the engine better than focusing only on one specification. For this reason, oil capacity should always connect with other maintenance factors such as oil type, oil level checks, and replacement timing.
